higher working performance and low cost to help the steel mills reduce their rolling mill cost;
mostly used in metal, and aluminum rolling mills;
![]() |
Boundary Dimensions | d | 280 | mm | |||
| D | 380 | mm | |||||
| B | 100 | mm | |||||
| Fw | 312 | mm | |||||
| Basic Load Ratings | Cr | 850 | kN | ||||
| C0r | 2100 | kN | |||||
| Speed Ratings | Grease | 1000 | rpm | ||||
| Oil | 1250 | rpm | |||||
| Weight | 36 | Kg | |||||
| Equivalent | SKF | FAG | NSK | NTN | KOYO | TIMKEN | URB |
| NNU4956 | NNU4956 | ||||||
radial clearance is generally executed in C3 or C4;
higher rolling efficiency with inner rings remained onto the rolls during processing;
